Brand New
€39
incl. VAT
€32.77 excl. VAT
Out of stock
The MC110CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC110CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC110CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data.
Specifications
Warranty
Warranty Products Returnable
Yes
Warranty Term (month)
36 month(s)
Warranty Validation Criteria
Serial Number
Networking Specifications
Number of Ports
1 x 100Base-FX (Ethernet/Fast Ethernet)
1 x 10Base-T/100Base-T (Ethernet/Fast Ethernet)
1 x 10Base-T/100Base-T (Ethernet/Fast Ethernet)
Networking Compliant Standards
IEEE 802.3x
IEEE 802.3
IEEE 802.3u
IEEE 802.3
IEEE 802.3u
Device Location
External
Certifications
FCC, CE
Data Transmission
Full Duplex
Networking Features
MDI/MDI-X switch
Auto-Negotiation
Auto-Negotiation
Data Bit Rate
100 Mbps
Interface Provided
Ethernet 10Base-T/100Base-TX Port Quantity
1
Ethernet 10Base-T/100Base-TX Port Connector Type
RJ-45
Ethernet 100Base-FX Port Quantity
1
Ethernet 100Base-FX Port Connector Type
SC
Power
Power Device Location
External
Dimensions & Weight Device
Depth (mm)
73 mm
Height (mm)
27 mm
Width (mm)
94.5 mm
Environment
Maximum Operating Ambient Temperature
40 °C
Maximum Operating Humidity
90 %
Minimum Operating Ambient Temperature
0 °C
Minimum Operating Humidity
10 %
TP-LINK Network Switch MC110CS
39
€
